Rockford Fosgate TM500X1BR
Power Series marine/powersports mono subwoofer amplifier — 500 watts RMS x 1 at 1 ohm
Compact design, really big sound
Rockford Fosgate designed their Power Series TM500X1BR mono amplifier for marine and powersports applications. This rugged, marine-rated subwoofer amp puts out some serious power, great news if you're big on bass.
Rockford Fosgate's patented Boosted Rail technology allows the amp to draw very little current during normal use, while it stores up a reserve for those times when you really crank up the volume. The low-pass filter and bass boost allow you to get maximum performance out of your sub and its enclosure. This amp will provide outstanding power and versatility in a variety of vehicles on land and sea.
Tough enough to handle moisture and heat
The TM500X1BR is built to stand up to outdoor life, too, with conformal-coated circuitry that withstands moisture and dirt and stainless steel hardware that won't succumb to corrosion. With a 3-stage thermal lock extrusion, dual- fan forced induction system, and real-time thermal monitoring, this amp can rock hard without overheating – even when it's tucked into a tight space.
Level setting made easy
The TM500X1BR uses Rockford Fosgate's CLEAN level setting technology, so there's no more guesswork while setting your gain levels. Easy-to-see LED indicators identify clipping so you can set your amp up for maximum performance while eliminating distortion.
Confused about impedance? Check out our article on matching subs and amps.
Product highlights:
- mono marine/powersports amplifier
- 175 watts RMS x 1 at 4 ohms (500 watts peak)
- 300 watts RMS x 1 at 2 ohms
- 500 watts RMS x 1 at 1 ohm
- CEA-2006 compliant
- ultra-efficient Boosted Rail amp technology
- conformal-coated circuit board — suitable for power sports and marine applications
- marine-grade stainless steel hardware
- twin cooling fans and real-time thermal sensing
- hidden top-mount control panel
- CLEAN set-up technology with LED input/output indicators
- speaker-level inputs (speaker wire to RCA adapter required)
- variable low-pass filter (50-250 Hz at 12 dB/octave)
- bass boost: 0-18 dB at 45 Hz
- frequency response: 20-220 Hz
- fuse rating: 60A x 1 (fuse not included)
- dimensions: 8-5/16"W x 1-9/16"H x 4-1/4"D
- requires 8-gauge power and ground cable
What's in the box:
Rockford Fosgate TM500X1BR owner's manual
- Mono marine amplifier
- Power/ground/turn-on plug (installed)
- Speaker output plug (installed)
- 14" Input harness (2 RCA to 4-pin Molex)
- Amplifier Quick Setup
- Certificate of Performance Verification
