WDX12G5R.4 : 12 in. Dual 4-Ohm Subwoofer

Product details

With the new WDX12G5R.4 subwoofers, we’ve redefined the benchmark for earth-shaking bass. Are you ready to experience the difference? With the new WDX12G5R.4 subwoofers, we’ve redefined the benchmark for earth-shaking bass. Are you ready to experience the difference? Introducing the all-new WDX12G5R.4 Subwoofers. Crafted for those who demand only the best, the WDX Reference subwoofers are far beyond the ordinary. They are designed for true bass enthusiasts who expect nothing less than excellence from DB DRIVE. Let’s explore the cutting-edge features that set the WDX Reference subwoofers apart. Distinctive Look and Engineering: The WDX Reference subwoofers sport a completely new design, starting with the custom mounting gasket. This gasket ensures a perfect seal between the subwoofer and enclosure, eliminating rear-canceling waves for pure, uninterrupted bass. Advanced Components for Superior Performance: One glance, and you’ll notice the all-new dust caps.

Features

• 3.0″ 4 layer Anodized aluminum high temperature voice coil
• Non-Pressed paper cone
• Double-stitched reinforced foam surround
• Dual poly-cotton dampeners
• Die-cast aluminum vented basket
• Rubber gasket trim ring
• Large gauge compression terminals
• Protective magnet cover

Specifications

• Dynamic Power Handling: 6000 Watts
• Nominal Power Handling: 3000 Watts
• Impedance: Dual 4Ω Voice Coil
• Resonant Frequency (fs): 31.513 Hz
• D.C. Voice Coil Resistance (Re): 2 x 3.2Ω
• Mechanical Quality Factor (Qms): 3.336
• Electrical Quality Factor (Qes): 0.579
• Total Quality Factor (Qts): 0.494
• Equivalent Air Volume (Vas): 22.988 L
• Mechanical Compliance of Suspension (CMS): 60.158 mm/N
• Mass of Diaphragm/Coil (Mms): 423.998 g
• Force Factor (BL): 30.454
• Sound Pressure Level (SPL): 82.8 dB
